Functional Architecture Intel® Workstation Board S5520SC TPS
Revision 1.7
Intel order number: E39530-010
20
Error Severity System Action
Processor frequency
(speed) not identical
Halt The BIOS detects the error condition and responds as follows:
– Adjusts all processor frequencies to the highest common frequency.
– No error is generated – this is not an error condition.
– Continues to boot the system successfully.
If the frequencies for all processors cannot be adjusted to be the same, then
the BIOS:
– Logs the error into the SEL.
– Displays “0197: Processor 0x family is not supported” message in the
Error Manager.
– Halts the system and will not boot until the fault condition is remedied.
Processor Intel®
QuickPath Interconnect
speeds not identical
Halt The BIOS detects the error condition and responds as follows:
– Adjusts all processor QPI frequencies to highest common frequency.
– No error is generated – this is not an error condition
– Continues to boot the system successfully.
If the link speeds for all QPI links cannot be adjusted to be the same, then the
BIOS:
– Logs the error into the SEL.
– Displays “0195: Processor 0x Intel® QPI speed mismatch” message in the
Error Manager.
– Halts the system and will not boot until the fault condition is remedied.
Processor microcode
missing
Minor The BIOS detects the error condition and responds as follows:
– Logs the error into the SEL.
– Does not disable the processor.
– Displays “8180: Processor 0x microcode update not found” message in
the Error Manager or on the screen.
– The system continues to boot in a degraded state, regardless of the
setting of POST Error Pause in Setup.
3.2.3 Intel
®
Hyper-Threading Technology (Intel
®
HT)
If the installed processor supports the Intel
®
Hyper-Threading Technology, the BIOS Setup
provides an option to enable or disable this feature. The default is enabled.
The BIOS creates additional entries in the ACPI MP tables to describe the virtual processors.
The SMBIOS Type 4 structure shows only the installed physical processors. It does not
describe the virtual processors.
Because some operating systems are not able to efficiently use the Intel
®
HT Technology, the
BIOS does not create entries in the Multi-Processor Specification, Version 1.4 tables to describe
the virtual processors.
3.2.4 Enhanced Intel SpeedStep
®
Technology (EIST)
If the installed processor supports Enhanced Intel SpeedStep
®
Technology, the BIOS Setup
provides an option to enable or disable this feature. The default is enabled.
