Intel

Solid-State Drive DC P3600 Series

Product Specification October 2014

10 330569-004US

2 Product Specifications

2.1 Capacity

Table 3: User Addressable Sectors

Intel SSD DC P3600 Series

Unformatted Capacity

(Total User Addressable Sectors in LBA Mode)

400GB

781,422,768

800GB

1,562,824,368

1.2TB

2,344,225,698

1.6TB

3,125,627,568

2TB

3,907,029,168

NOTE: 1 GB = 1,000,000,000 bytes; 1 sector = 512 bytes or 520 bytes or 528 bytes. LBA count shown

represents total user storage capacity and will remain the same throughout the life of the drive.

The total usable capacity of the SSD may be less than the total physical capacity because a small

portion of the capacity is used for NAND media management and maintenance. IDEMA or JEDEC

standard is used.

2.2 Performance

Table 4: Random Read/Write Input/Output Operations Per Second (IOPS)

Specification

Unit

Intel SSD DC P3600 Series

400GB

800GB

1.2TB

1.6TB

2TB

Random 4KB 70/30 Read/Write

(up to)

IOPS

80,000

110,000

130,000

160,000

Random 8KB 70/30 Read/Write

(up to)

IOPS

45,000

55,000

65,000

75,000

80,000

Random 4KB Read

(up to)

IOPS

320,000

430,000

450,000

Random 4KB Write (up to)

IOPS

30,000

50,000

56,000

Random 8KB Read

(up to)

IOPS

180,000

250,000

260,000

270,000

275,000

Random 8KB Write

(up to)

IOPS

19,000

26,000

27,000

33,000

NOTES:

1. Performance measured using IOMeter* on Intel provided Windows Server 2012 R2 driver with Queue Depth 32 and

number of workers equal to 4. Measurements are performed on a full Logical Block Address (LBA) span of the drive.

Power mode

set at 25W.

2. 4KB = 4,096 bytes

3. 8KB = 8,192 bytes
