C H A P T E R 2 Intel Device View

After a Switch or Stack is Contacted

Commands When Intel Device View contacts a switch, the basic commands are

supplemented with:

• Local Management access — provides Telnet access to monitor-

ing functions embedded in the switch.

• RMON facility — gathers information about the network traffic,

monitors traffic on subnets and enables you to define alarms on

the individual ports.

• Stack Synchronization Manager (for stacks only) — enables you

to establish a stack from a group of switches connected via a

Matrix Module, or add a switch to an existing stack and then syn-

chronize their configurations.

• Switch Position Organizer (for stacks only) — enables you to

move the switches displayed on screen around in the stack.

• Color Code Matrix Ports (for stacks only) — colors the individ-

ual ports on the Matrix Module. This simplifies the task of trac-

ing cables, as the ports on the Stack Interface Modules become

the same color as the corresponding Matrix Module port.

• A color coding chart for Intel Device View to show the states of

switch’s LEDs

500.book Page 23 Thursday, September 2, 1999 1:50 PM
